RG179 SMB Female To SMB Female Cable , Antenna Coaxial Cable Length 325mm

Name: RG179 SMB Female To SMB Female Cable Antenna Coaxial Cable Length 325mm
Brand: CSCE
Price: 1 USD

Buy cheap RG179 SMB Female To SMB Female Cable , Antenna Coaxial Cable Length 325mm product

Brand Name : CSCE

Model Number : SC4-SMBA325034

MOQ : 500pcs

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 150K pcs/day

Delivery Time : 7-10 days

Packaging Details : PE BAG in Carton

Certification : RoHS/CE/UL/FCC/CE/ISO9001/ISO14001

Place of Origin : Shenzhen,China

Vswr : ≤1.5

Impedance : 75 Ohm

Color : brown or customized

Cable length : 325mm or customized

Cable : RG179 or customized

name : SMB Female To SMB Female Cable

Contact Now

SMB Female/Plug To SMB Female Plug Cable Assembly Antenna Coaxial Cable RG179

Quick Details:

Specification:	Antennas	Cross Part NO:	SC4-SMBA325034
Mounting:	SMB	Samples:	Available 2-3 Pcs

Product Details:

Impedance	75 Ohms
Mfg Insertion Loss/Resturn Loss	100% Test
VSWR	≤1.5
Overall Cable Insertion Loss	≤-1.0dB
Working Voltage	500 Vnms MAX
Storage Temperature	-40℃~+85℃
Insulation Resistance	≥500m Ohms
Center Contact Resistance	≤25m Ohms
Storage Period	2 Years
Perating Temperture Range	-40℃~+85℃
Frequency Range	DC To 1GHz
Mfg Open/Short	100% Test
Outer Contact Resistance	≤15m Ohms

Why Choose Us

World’s Leader Supplier Of Integrated Connector And Discrete Magnetic Transformers

14Years Experience

Our company since 2005 network connector production in the past 14 years,only focus on network connector design and development and production and sales.

OEM Services

For high-quality, high reliability and reasonable price network connector products,and more than the word’s top 500 OEM manufacturers recognized.

Production Ability

The company’s own injection molding, stamping and automated assembly plant, a professional automated production and testing equipment, the company has established an independent laboratory.

Product Drawing:
